Description GOODS

Details

CLARITY

ADVANCED INDUSTRY MACHINE

ACTUAL PRINT SIZE

4000MM X12000MM

PRINT HEAD TYPE TO

ADANCE INDUSTIAL PRINTING HEAD SPECIAL DESIGN

INK SUPPLY SYSTEM

Double CHANNEL 12 COLOR AND INK CARTIDGES

SUITABLE MATERIALS

SUITABLE FOR A VARIETY OF SPECIAL MATERIAL : INTERIOR AND EXTERIOR WALL ,PUTTY POWER WALL LATEX PAINT, WHITE WALL ,IMITATION PORCELAIN WALL , DIATOM MUD WALL ,CANVAS , TILES .GLASS , RICE PAPER, WALL CLOTHING ,COLOR COATED GLAZE , SHELL POWDER ,COLOR PAINT AND SO ON .

MOTOR TECHNOLOGY

BRUSHLESS SERVO MOTOR VECTOR POSITIONING TECHNOLOGY FIVE STAR GRATING

PRINT SPEED

HIGH ,MEDIUM ,LOW ,THREE SPEED ADJUSTABLE

PRINTING RESOLUTION

360 *720 DPI OR 720 *720DPI OR 720 *1080 DPI

OR 720 *1440 DPI

PICTURE TYPE

SUPPORT JPG, BMP, TIFF, PDF, AI, PSD, CDR AND OTHER FILES (SOME FORMATS NEED TO BE CONVERTED)

POWER SUPPLY

AC110V(90-132V)/AC220V(180-264V)AC,47-63HZ

POWER CONSUMPTION

NO-LOAD 20W, GENERAL 75W, MAX TO 250W

NOISE

STANDBY <20DBA, DRAWING <50DBA

OPERATION

-10?-60?(14?-140?)10%-80% relative humidity, non condensable

STORAGE

-30?-60?(-22?-140?)10%-80% relative humidity, non condensable

SYSTEM PLATFORM

Windows XP/Win 7/Win 8/Win 9/Win 10

MOTHERBOARD

MACHINE LANGUAGE

FRANCH,ARABIC ,English(Customizable)

PRINT MODE

14 Plane / hour

QUICK MODE

18Plane / hour
